Alloy Steel Grease Injection Control Head with 10000psi Working Pressure and Hammer Union Connection for Wireline Operations
Alloy Steel Grease Injection Control Head with 10000psi Working Pressure and Hammer Union Connection for Wireline Operations Alloy Steel Grease Injection Control Head with 10000psi Working Pressure and Hammer Union Connection for Wireline Operations
Contact nu

Alloy Steel Grease Injection Control Head with 10000psi Working Pressure and Hammer Union Connection for Wireline Operations

Min. bestelaantal : 1 set Prijs : USD 1-10000/set
Verpakking Details : Pollywood Levertijd : 30-50 dagen
Betalingscondities : L/c, t/t, d/p Levering vermogen : 10 set/maand
Plaats van herkomst: CHINA Merknaam: ZZ TOP OIL TOOLS
Certificering: ISO, API Modelnummer: Vet injectiecontrolekop

Gedetailleerde informatie
Product: Vet injectiecontrolekop Materiaal: Legeringsstaal
Werkdruk: 10000psi Sollicitatie: Telefoonlijnverrichting
Gebruik: Wireline drukregelapparatuur Verbinding: Hamer Unie
Wokring Temp.: -29~121℃
Markeren:

10000psi Grease Injection Control Head

,

Hammer Union Grease Injection Control Head

,

Alloy Steel Wireline Pressure Control Equipment

Productomschrijving

Grease Injection Control Head Assembly with Stuffing box and Wireline Wiper

The Grease Injection Control Head is a sealing device designed for braided cable wireline operations, providing effective wireline sealing functionality. This essential component is used across various oil and gas well applications where pressure control is critical during wireline operations, particularly when fluid or gas loss cannot be tolerated.

Key Features
  • Positioned at the top of the pressure control equipment string
  • Combines Line Wiper Bell, Stuffing Box, Flow Tubes assembly, and ball check valve
  • Essential for maintaining well integrity during high-pressure operations
Technical Specifications
Wire Size Working Pressure Qty. Of Stuffing Box Qty. Of Flow Tubes Qty. Of Hydraulic Port Qty. Of Grease Injection Port Qty. Of Grease Return Port Service Working Temperature
7/32"
5/16"
15/32"		 5000Psi 1 4 2 1 1 STD or H2S P+U -20°F~+250°℉
Or As Required
10000Psi 1 6 2 1 1
15000Psi 2 9 3 2 1
Alloy Steel Grease Injection Control Head with 10000psi Working Pressure and Hammer Union Connection for Wireline Operations 0
